PS2802-1-F3-A Real Image PS2802-1-F3-A real image4957
Same model may have multiple batches, images only for reference.
PS2802-1-F3-A Real Image PS2802-1-F3-A real image4957
PS2802-1-F3-A Real Image PS2802-1-F3-A real image4957
Same model may have multiple batches, images only for reference.

PS2802-1-F3-A

Part No PS2802-1-F3-A
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLATOR 2.5KV DARL 4SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 200% @ 1mA
Rise and Fall Time 200μs, 200μs
Input Type DC
Output Type Darlington
Maximum Output Voltage 40V
Channel Output Current 90mA
Forward Voltage 1.1V
Continuous forward current- Max 50mA
Vce Saturation (Max) 1V
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 4-SSOP
Win Source Part Number 102918-PS2802-1-F3-A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PS2802-1-F3-A CAD Model

Description

The CEL PS2802-1-F3-A is an optoisolator with a Darlington output.

  • Product Name: CEL PS2802-1-F3-A
  • Output Type: Darlington
  • Channel Count: One
  • Minimum DC Current Transfer Ratio: 200% @ 1mA
  • Application: Commonly used in applications where electrical isolation is required between input and output circuits.
  • Isolation Voltage: 2500Vrms
  • Supply and Demand Status: Sufficient
  • Temperature Range: -55°C to 100°C
  • Rise and Fall Time: 200μs
