Same model may have multiple batches, images only for reference.
UPB1007K-E1-A real image
Same model may have multiple batches, images only for reference.

UPB1007K-E1-A

Part No UPB1007K-E1-A
Manufacturer CEL
Catalog RF Mixers
Description IC MIXR 1575.42MHZ DWNCONV 36QFN
Datasheet
UPB1007K-E1-A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer CEL
Packaging Reel - TR
Status Obsolete(EOL)
RF Type GPS
Frequency 1575.42MHz
Number of Mixers 2
Gain 15.5dB
Noise Figure 3.2dB
Secondary Attributes Down Converter
Operating Supply Current 35mA
Supply Voltage - Operating 2.7 V to 3.3 V
Case / Package 36-QFN (6x6)
Win Source Part Number 052968-UPB1007K-E1-A
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian UPB1007K-E1-A CAD Model

Description

The CEL UPB1007K-E1-A is a down converter designed for use in GPS applications.

  • It has a frequency of 1575.42MHz and a gain of 15.5dB.
  • The noise figure is 3.2dB, and the RF type is GPS.
  • The product has a secondary attribute of down converter and has two mixers.
  • It is packaged in a 36-QFN (6x6) case, and the supply voltage for operating is 2.7V to 3.3V.
  • The operating supply current is 35mA.
  • The product is considered obsolete (EOL), and its popularity is high.
