Products specifications Report Issue?

Manufacturer Ceramate Technical
Win Source Part Number 1121036-10D241K
Manufacturer Homepage www.ceramate.com.tw
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 10D241K CAD Model

Description

The 10D241K is a varistor manufactured by Ceramate Technical, designed to protect electronic circuits from voltage surges and transients. It is commonly used in power supplies, telecommunications equipment, and industrial control systems to absorb excess voltage and prevent damage to sensitive components. The '241' indicates a voltage rating of 240V, and 'K' indicates a tolerance of ±10%.

Applications:

  • Power supplies
  • Telecommunications equipment
  • Industrial control systems
  • Surge protection devices
  • Transient voltage suppression

Features:

  • Varistor (Voltage Dependent Resistor)
  • High surge current capability
  • Fast response time
  • Wide operating voltage range
  • Compact size

Benefits:

  • Provides effective protection against voltage surges and transients.
  • Reduces the risk of damage to sensitive electronic components.
  • Enhances the reliability and lifespan of electronic devices.
  • Offers fast response to transient events.
  • Easy to integrate into existing circuit designs.

Additional Details:

The 10D241K varistor operates by changing its resistance in response to voltage variations. When the voltage exceeds its rated value, the resistance drops dramatically, diverting the surge current away from the protected circuit. The energy handling capability is a crucial parameter, indicating the amount of energy the varistor can absorb without failure. The clamping voltage specifies the voltage level at which the varistor starts to conduct significantly. Proper selection of the varistor's voltage rating is essential to ensure adequate protection without causing nuisance tripping. The datasheet provides detailed specifications, including surge current ratings, clamping voltage characteristics, and operating temperature ranges.

In summary, the 10D241K varistor is a reliable and cost-effective solution for protecting electronic circuits from voltage surges, ensuring the longevity and stability of sensitive equipment.
