CMT2N7002X

Part No CMT2N7002X
Manufacturer Champion Microelectronic Corp.
Catalog END - OF - LIFE
Description SMALL SIGNAL MOSFET
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Champion Microelectronic Corp.
Win Source Part Number 1162557-CMT2N7002X
Manufacturer Homepage www.champion-micro.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian CMT2N7002X CAD Model

Description

The CMT2N7002X is an N-Channel enhancement mode MOSFET manufactured by Champion Microelectronic Corp. This MOSFET is designed for low voltage, high-speed switching applications and is frequently used in portable devices and other low-power systems. Its small size and efficient performance make it suitable for compact electronic designs.

Applications

  • Low voltage switching
  • Portable equipment
  • Battery-powered devices
  • Load switching
  • DC-DC converters

Features

  • N-Channel enhancement mode: Easy to drive and control with standard logic levels.
  • Low gate threshold voltage: Allows for operation with low voltage control signals.
  • Fast switching speed: Enables high-frequency operation with minimal switching losses.
  • Small SOT-23 package: Ideal for space-constrained applications.
  • RoHS compliant: Environmentally friendly manufacturing process.

Benefits

  • Efficient power management: Low on-resistance reduces power dissipation and improves battery life.
  • Simplified circuit design: Compatible with low voltage logic simplifies the drive circuitry.
  • High-speed performance: Fast switching characteristics enhance overall system performance.
  • Miniaturized design: Compact package allows for smaller and more portable devices.
  • Environmentally responsible: RoHS compliance minimizes environmental impact.

Additional Details

The CMT2N7002X has a drain-source voltage rating of 60V, and a typical continuous drain current of around 300mA. The gate threshold voltage is typically between 1V and 3V. It is housed in a SOT-23 package, which is well-suited for automated assembly. This MOSFET is commonly used in applications where efficient power management and small size are critical requirements. The device is designed to provide reliable and consistent performance in a variety of operating conditions.
