Manufacturer Chenmko
Win Source Part Number 1152626-BD4148FPT
Manufacturer Homepage www.chenmko.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BD4148FPT CAD Model

Description

The BD4148FPT is a high-speed switching diode manufactured by Chenmko. This diode is designed for applications requiring fast switching speeds and low forward voltage drop. It is commonly used in signal processing, high-speed switching circuits, and general-purpose rectification.

Applications:

  • High-Speed Switching Circuits
  • Signal Processing
  • General Purpose Rectification
  • Voltage Clamping
  • Protection Circuits

Features:

  • High Switching Speed: Fast reverse recovery time for high-frequency applications.
  • Low Forward Voltage Drop: Reduces power dissipation and improves efficiency.
  • Small Package Size: Compact design for space-constrained applications.
  • High Reliability: Robust construction for reliable performance.
  • Surface Mount Device: Suitable for automated assembly processes.

Benefits:

  • Improved Performance: Fast switching speed enhances circuit performance in high-frequency applications.
  • Increased Efficiency: Low forward voltage drop minimizes power losses.
  • Compact Design: Small package size allows for high-density circuit designs.
  • Reliable Operation: Robust design ensures stable and consistent performance.
  • Cost-Effective: Provides a high-performance solution at a reasonable cost.

Technical Specifications:

The BD4148FPT features a maximum reverse voltage (VR) of 100V, a maximum forward current (IF) of 200mA, and a forward voltage drop (VF) of typically 0.72V at IF = 10mA. The reverse recovery time (trr) is typically 4 ns. It is available in a SOD-523 package. The operating junction temperature range is from -65°C to +150°C. The diode capacitance is approximately 4 pF.

The BD4148FPT is a versatile diode suitable for a wide range of high-speed switching and signal processing applications. Its combination of fast switching speed, low forward voltage drop, and compact size makes it a preferred choice for designers seeking efficient and reliable diode performance.
