AP2302DTR-E1 Chipown
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Manufacturer Chipown
Win Source Part Number 54781-AP2302DTR-E1
Popularity Low
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AP2302DTR-E1 CAD Model

Description

AP2302DTR-E1 - High-Performance MOSFET

The AP2302DTR-E1 is a high-performance MOSFET designed to optimize energy efficiency in electronic devices. With its minimal on-resistance and excellent thermal performance, this component is ideal for various applications.

  • Applications & Projects:
    • Switch mode power supplies
    • DC-DC converters
    • Battery management systems
    • Motor control systems
  • Features & Benefits:
    • Low on-resistance for enhanced efficiency
    • High-speed switching capabilities
    • Robust thermal performance for reliable operation
    • Compact design suitable for space-constrained applications
  • Additional Details:
    • Part Number: AP2302DTR-E1
    • Package: Available in a surface-mount package for easy integration
