MS3475W14-4P

Part No MS3475W14-4P
Manufacturer Conesys
Catalog Circular Connectors - Assemblies
Description CONN PLUG MALE 4POS GOLD CRIMP / 4 Position Circular Connector Plug, Male Pins Crimp
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Circular Connectors>Circular Connector Assemblies
Mfr Conesys
Series Military, MIL-DTL-26482 Series II
Package Box
Connector Type Plug, Male Pins
Number of Positions 4
Shell Size - Insert 14-4
Shell Size, MIL -
Mounting Type Free Hanging (In-Line)
Mounting Feature -
Termination Crimp
Fastening Type Bayonet Lock
Orientation N (Normal)
Primary Material Metal
Shell Material Aluminum Alloy
Shell Finish Olive Drab Cadmium
Contact Finish - Mating Gold
Color Olive Drab
Ingress Protection -
Features -
Shielding Shielded
Current Rating (Amps) -
Voltage Rating -
Temperature Range - Operating -55°C ~ 200°C
Contact Finish Thickness - Mating 50.0µin (1.27µm)
Base Product Number MS3475W14
RoHS Status RoHS non-compliant
ECCN EAR99
HTSUS 8536.69.4020
Standard Package 1 pcs
Win Source Part Number 1382958-MS3475W14-4P
Ultra Librarian 3D Model Ultra Librarian MS3475W14-4P CAD Model

Description

The 1200094 is a circular connector assembly designed by Conesys.

  • Series: Military
  • Standard: MIL-DTL-26482 Series II
  • Connector Type: Plug with Male Pins
  • Fastening Type: Bayonet Lock
  • Number of Positions: 4
  • Shielding: Yes
  • Operating Temperature: -55°C to 200°C
  • Body Material: Aluminum Alloy
  • Body Finish: Olive Drab Cadmium
  • Contact Finish: Gold
