Same model may have multiple batches, images only for reference.

DHS100B05

Name: DHS100B05
Brand: Cosel USA, Inc.
SKU: 1063454
Availability: InStock
Rating: 4.91 (5 reviews)

Get a Quote

Part No	DHS100B05
Manufacturer	Cosel USA, Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 5V / Isolated Module DC DC Converter 1 Output 5V 20A 200V - 400V Input
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Mfr	Cosel USA, Inc.
Series	DHS (100W)
Package	Box
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	200V
Voltage - Input (Max)	400V
Voltage - Output 1	5V
Current - Output (Max)	20A
Voltage - Isolation	3 kV
Applications	ITE (Commercial)
Features	Remote On/Off, OCP, OTP, OVP
Temperature Range - Operating	-40°C ~ 100°C
Efficiency	82%
Mounting Type	Through Hole
Package / Case	6-DIP Module
Dimension	2.30" L x 1.47" W x 0.50" H (58.4mm x 37.3mm x 12.7mm)
Base Product Number	DHS100
MSL Level	Not Applicable
ECCN	EAR99
HTSUS	8504.40.9580
Other Names	1776-1199
Standard Package	1
Win Source Part Number	1063454-DHS100B05
Ultra Librarian 3D Model	Ultra Librarian DHS100B05 CAD Model

Alternative Products

Description

The DHS (100W) electronic component is an isolated module type DC DC converter with a remote On/Off feature, OCP, OTP, and OVP. DHS (100W) is from Cosel USA, Inc..

Type: Isolated module DC DC converter
Features: Remote On/Off, OCP, OTP, OVP
Current Output: 20A
Efficiency: 82%
Win Source Part Number: 1063454-DHS100B05
Application: ITE (Commercial)
Voltage Isolation: 3 kV
