Same model may have multiple batches, images only for reference.
PDS1-S12-S12-S Real Image
Same model may have multiple batches, images only for reference.

PDS1-S12-S12-S

Part No PDS1-S12-S12-S
Manufacturer CUI Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 12V 1W / Isolated Module DC DC Converter 1 Output 12V 83mA 10.8V - 13.2V Input
Datasheet
PDS1-S12-S12-S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount>DC DC Converters
Manufacturer CUI Inc.
Packaging Tube
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 10.8V
Voltage - Input (Max) 13.2V
Voltage - Output 1 12V
Current - Output (Max) 83mA
Power (Watts) 1 W
Voltage - Isolation 1.5 kV
Applications ITE (Commercial)
Features SCP
Temperature Range - Operating -40°C ~ 105°C (With Derating)
Efficiency 81%
Mounting Through Hole
Case / Package 4-SIP Module
Size / Dimension 0.46" L x 0.24" W x 0.40" H (11.6mm x 6.0mm x 10.2mm)
Approval Agency CB Scheme, EN, IEC, UL
Standard Number 55024; 55032 Class A; 60950-1
Base Product Number PDS1-S12
RoHS Status RoHS Compliant
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Other Part Number 102-2737,PDS1S12S12S
Standard Package 43
Win Source Part Number 1320697-PDS1-S12-S12-S
Ultra Librarian 3D Model Ultra Librarian PDS1-S12-S12-S CAD Model

Description

The PDS1-S12-S12-S from CUI Inc. is a non-isolated PoL module DC-DC converter that comes with a through-hole mounting style.

  • Power: 1 W
  • Current Output: 83mA
  • Voltage Input: 10.8V to 13.2V
  • Voltage Output: 12V
  • Voltage Isolation: 1.5 kV
  • Feature: Short Circuit Protection (SCP)
  • Package: 4-SIP module
  • Standard Package: 43
  • RoHS Compliant: Yes
  • Standard Number: 55024; 55032 Class A; 60950-1
