Same model may have multiple batches, images only for reference.
PRQ100W-Q48-S24-D Real Image
Same model may have multiple batches, images only for reference.

PRQ100W-Q48-S24-D

Part No PRQ100W-Q48-S24-D
Manufacturer CUI Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 24V 101W / Isolated Module DC DC Converter 1 Output 24V 4.2A 18V - 75V Input
Datasheet
PRQ100W-Q48-S24-D Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount - DC DC Converters
Mfr CUI Inc.
Series PRQ100W-D (100W)
Package Tray
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 18V
Voltage - Input (Max) 75V
Voltage - Output 1 24V
Current - Output (Max) 4.2A
Power (Watts) 101 W
Voltage - Isolation 2.25 kV
Applications ITE (Commercial)
Temperature Range - Operating -40°C ~ 85°C (With Derating)
Efficiency 93%
Mounting Type Through Hole
Package / Case Quarter Brick
Size / Dimension 2.43" L x 1.58" W x 0.50" H (61.8mm x 40.2mm x 12.7mm)
Supplier Device Package Quarter Brick
Approval Agency CE
Base Product Number PRQ100W
Standard Package 24
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 1351077-PRQ100W-Q48-S24-D
Ultra Librarian 3D Model Ultra Librarian PRQ100W-Q48-S24-D CAD Model

Description

The CUI Inc. PRQ100W-D (100W) series DC-to-DC converter, PRQ100W-Q48-S24-D, is a 101W power supply module in a quarter brick package.

  • Series: PRQ100W-D (100W)
  • Voltage Input: 18V to 75V
  • Voltage Output: 24V
  • Efficiency: 93%
  • Maximum Output Current: 4.2A
  • Voltage Isolation: 2.25 kV
  • Application: ITE (Commercial)
  • Approval: CE
  • Temperature Range: -40°C to 85°C with derating
