Same model may have multiple batches, images only for reference.
AM29F040B-70JF real image1813
Same model may have multiple batches, images only for reference.

AM29F040B-70JF

Part No AM29F040B-70JF
Manufacturer Cypress Semiconductor Corp
Catalog Flash
Description IC FLASH 4MBIT 70NS 32PLCC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Cypress Semiconductor Corp
Packaging Tray
Status Obsolete(EOL)
Memory Format FLASH
Technology FLASH
Memory Size 4Mb (512K x 8)
Access Time 70ns
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 32-PLCC
Win Source Part Number 087483-AM29F040B-70JF
Family Name AM29F040B
Introduction Date June 21, 1996
ECCN EAR99
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AM29F040B-70JF CAD Model

Description

AM29F040B-70JF

The AM29F040B-70JF delivers robust flash memory solutions designed to meet demanding storage needs in modern electronic devices. Providing quick access and reliable performance, it caters to a broad spectrum of applications with simplicity of use.

  • Features and Benefits<ul>
  • 4 Mbit memory storage capability
  • 70 ns fast access time for efficient data retrieval
  • JEDEC standard package for versatile deployment
  • Optimal for high endurance with low power consumption
  • Common Applications and Projects<ul>
  • Data-driven telecommunication equipment
  • Digital displays and signage projects
  • Wearable technology development
  • Internet of Things (IoT) solutions

    • The chip's design emphasizes durability and compatibility, making it an apt choice for high-performance electronic components that require reliable memory integration.
