Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Estimated Pruduction Lead Time 10 Weeks
Features Enclosed AC DC Converters 1 Uitgang 12V - - - 333mA 85 ~ 264 VAC, 120 ~ 370 VDC Input
Manufacturer Delta Electronics
Series AA04S (4W)
Package Box
Operating Temperature Range -25°C ~ 60°C (With Derating)
Mounting Through Hole
Package 7-DIP Module, 6 Leads
Family Name AA04S
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.6018
Quantity per package 1
Popularity High
Supply and Demand Status Balance
Win Source Part Number 909095-AA04S1200A
Ultra Librarian 3D Model Ultra Librarian AA04S1200A CAD Model

Description

The Delta Electronics AA04S1200A is an enclosed AC DC converter that has a single output of 12V and can deliver an output current of 333mA. The device has an input voltage range of 85 ~ 264 VAC, 120 ~ 370 VDC and can operate in a temperature range of -25°C ~ 60°C (With Derating).

  • Type: Enclosed AC DC Converter
  • Output: 12V @ 333mA
  • Input Voltage: 85 ~ 264 VAC, 120 ~ 370 VDC
  • Operating Temperature: -25°C ~ 60°C (With Derating)
  • Package: 7-DIP module, 6 leads
  • Popularity Rating: High
  • Estimated Production Lead Time: 10 weeks
