Product Overview: AZ1117EH-3.3TRG1

The AZ1117EH-3.3TRG1 is a robust low dropout (LDO) linear voltage regulator designed and manufactured by Diodes Incorporated. This high-performance component is engineered to deliver a fixed output voltage of 3.3V, making it an ideal choice for a wide range of electronic applications where a stable and reliable power supply is crucial.

Key Features

• Output Voltage: The device provides a stable 3.3V output, which is essential for powering sensitive electronic circuits that require a consistent voltage level.
• High Efficiency: With its low dropout voltage, the AZ1117EH-3.3TRG1 ensures efficient operation even when the input voltage is close to the output voltage, reducing power loss and improving overall system efficiency.
• Current Capacity: It can deliver an output current of up to 1A, which is sufficient for a variety of low-power devices and applications.
• Thermal Protection: The regulator includes built-in thermal shutdown functionality, which protects the device from overheating by turning off the output when the internal temperature exceeds safe operating limits.
• Short Circuit Protection: The AZ1117EH-3.3TRG1 is equipped with short circuit protection to safeguard the regulator and the connected load in the event of a fault condition.
• Package Type: This component is available in a SOT-223 package, which is known for its compact footprint and excellent power dissipation characteristics.

Applications

The AZ1117EH-3.3TRG1 is versatile and can be used in various electronic devices, including:

• Consumer Electronics
• Computer Peripherals
• Networking Equipment
• Portable Devices
• Power Management Solutions

Quality and Reliability

Diodes Incorporated is committed to delivering high-quality products. The AZ1117EH-3.3TRG1 is produced with rigorous quality control processes and is designed to meet the stringent requirements of the electronics industry. The reliability of this LDO regulator makes it a preferred choice for designers and engineers seeking a dependable power management solution.

With its combination of performance, efficiency, and protection features, the AZ1117EH-3.3TRG1 from Diodes Incorporated stands out as a solid choice for any application requiring a 3.3V regulated power supply.
