The B530C-13-F is a high-performance Schottky barrier rectifier designed and manufactured by Diodes Incorporated, a leading company in the semiconductor market. This rectifier is specifically engineered to meet the needs of electronic applications requiring efficient power management and high reliability. With its compact footprint and robust features, the B530C-13-F is an ideal choice for a wide range of power conversion applications.

Key Features

• Low Forward Voltage Drop: The device offers a low forward voltage drop, which enhances power efficiency by minimizing power loss during conduction.
• High Surge Capability: It is designed to withstand high surge currents, making it suitable for applications prone to surges and spikes.
• Guard Ring Die Construction: The guard ring design provides transient voltage protection and ensures a long operational life by enhancing the device's reliability.
• Lead-Free Finish: The B530C-13-F comes with a lead-free finish, making it compliant with RoHS regulations and suitable for eco-friendly applications.

Applications

The versatility of the B530C-13-F allows it to be used in a variety of applications, including:

• Power supply units
• DC-DC converters
• Automotive applications
• Free-wheeling diodes in converters and motor control circuits
• Polarity protection applications

Technical Specifications

Parameter Value Package DO-214AB (SMC) Maximum Repetitive Reverse Voltage 30V Average Rectified Forward Current 5A Peak Forward Surge Current 150A Operating Temperature Range -55°C to +150°C

Quality and Compliance

Diodes Incorporated is committed to providing high-quality products. The B530C-13-F is manufactured in facilities that are certified to ISO 9001:2015 standards, ensuring that every unit meets the highest quality and performance standards. Additionally, the product is RoHS compliant, reflecting the company's dedication to environmental responsibility.
