FZT849TA

Part No FZT849TA
Manufacturer Diodes Incorporated
Catalog Transistors (BJT) - Single
Description TRANS NPN 30V 7A SOT-223
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Diodes Incorporated
Packaging Reel - TR
Status Active
Transistor Polarity NPN
Maximum Current Collector 7A
VCEO Maximum Collector-Emitter Breakdown Voltage 30V
Max Vce (sat) 350mV @ 300mA, 6.5A
Collector Cut-off Current(Max) 50nA (ICBO)
Typical Gain (hFE) (Min) 100 @ 1A, 1V
Maximum Power Dissipation 3W
Frequency - Transition 100MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-223
Win Source Part Number 110495-FZT849TA
Family Name FZT849
Introduction Date October 28, 1997
ECCN EAR99
Country of Origin China, Germany
Halogen Free Compliant
Estimated EOL Date 2026
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian FZT849TA CAD Model

Description

The FZT849TA from Diodes Incorporated is a high-performance NPN bipolar junction transistor (BJT) designed for use in a wide range of electronic applications. Known for its robustness and efficiency, this transistor is a reliable choice for designers and engineers looking to enhance their circuit designs.

Key Features

  • High Current Capability: The FZT849TA is capable of handling continuous collector currents up to 7A, making it suitable for high-power applications.
  • High Power Dissipation: With a power dissipation rating of 2W, this transistor can withstand significant energy without performance degradation, ensuring long-term reliability.
  • High hFE: A high DC current gain (hFE) ensures that the transistor can amplify electrical signals effectively, making it ideal for audio amplification and signal processing applications.
  • High Voltage Rating: The collector-emitter voltage (VCEO) is rated at 30V, providing ample headroom for various circuit configurations.
  • Fast Switching Speed: The FZT849TA offers fast switching speeds, which is critical for applications requiring quick response times, such as switching regulators and drivers.

Applications

The versatile nature of the FZT849TA makes it suitable for a broad range of applications, including:

  • Power Management Circuits
  • DC-DC Converters
  • Motor Control Systems
  • Audio Amplifiers
  • Signal Processing
  • Switching Regulators
  • Driver Circuits

Package and Quality

The FZT849TA comes in an SOT-223 surface-mount package, which is compact and suitable for automated assembly processes. Diodes Incorporated ensures high-quality standards, with each transistor undergoing rigorous testing to meet the demands of various industries.

Environmental Compliance

Diodes Incorporated is committed to environmental sustainability. The FZT849TA complies with RoHS and Green standards, minimizing the environmental impact by avoiding the use of hazardous substances in its construction.

For detailed technical specifications, application notes, and support resources, customers are encouraged to visit the official Diodes Incorporated website or contact their local sales representative.
