Product Overview: PDS360-13 from Diodes Incorporated

The PDS360-13 is a high-performance Schottky barrier rectifier designed by Diodes Incorporated, renowned for its efficiency and reliability in a variety of applications. This rectifier is engineered to offer low forward voltage drop, high surge current capability, and a fast switching response, making it an excellent choice for high-frequency and energy-sensitive environments.

Key Features

• Low Forward Voltage Drop: The PDS360-13 boasts a low forward voltage drop, which enhances system efficiency by minimizing power loss during the conduction phase.
• High Surge Current Capability: This device can withstand high surge currents, ensuring durability and reliability in applications where transient current spikes are common.
• Fast Switching Response: With its quick response times, the PDS360-13 is ideal for high-frequency applications, providing efficient performance without compromising on speed.
• Power Dissipation: It has a power dissipation of 3.5W, which allows it to handle significant amounts of power while maintaining a compact form factor.
• Operating Junction Temperature: The rectifier operates within a wide temperature range, with a junction temperature from -55°C to +150°C, accommodating various environmental conditions.

Applications

The PDS360-13 is versatile and can be used in a variety of applications, including:

• Power Supply Units (PSUs)
• DC-DC Converters
• Freewheeling Diodes
• Reverse Battery Protection
• Automotive applications
• High-frequency rectification

Package and Quality Assurance

The PDS360-13 comes in a robust and compact DO-214AB (SMC) package, ensuring a minimal footprint on printed circuit boards (PCBs) while providing excellent thermal performance. Diodes Incorporated's commitment to quality ensures that each unit is manufactured to the highest standards, with rigorous testing to guarantee performance and reliability.

Environmental Compliance

Diodes Incorporated is dedicated to environmental stewardship. The PDS360-13 is compliant with RoHS, REACH, and other environmental directives, reflecting the company's commitment to reducing the environmental impact of its products.
