Product Overview: PI3B33X257BE from Diodes Incorporated

The PI3B33X257BE is a high-performance, 3.3V, 10-bit, 2-port bus switch from Diodes Incorporated, designed to provide unmatched signal integrity and drive strength. This device is part of the Pericom® product family and is well-suited for a wide range of applications, including computing, networking, communications, and consumer electronics.

Key Features

• Low On-Resistance: The PI3B33X257BE features a low on-resistance of 5Ω (typical), which ensures minimal signal distortion and power loss across the switch.
• Wide Bandwidth: With a bandwidth of over 500MHz, this bus switch is capable of supporting high-speed signal transmission without compromising signal integrity.
• Quick Switching Speed: The device offers a fast switching speed, with a typical turn-on time of only 0.25ns, making it ideal for applications that require rapid signal routing.
• Low Crosstalk: Engineered to minimize crosstalk, the PI3B33X257BE is an excellent choice for applications where signal isolation is critical.
• 5V Tolerant: This bus switch is 5V tolerant on all ports, allowing it to interface with both 3.3V and 5V logic levels.
• Power-Down High-Impedance: When powered down, the switch enters a high-impedance state, reducing power consumption and preventing unintended signal transmission.
• ESD Protection: The PI3B33X257BE comes with built-in ESD protection circuitry, safeguarding the device against electrostatic discharges.
• Packaging: Available in a space-saving 24-pin QSOP package, the switch is designed to meet the requirements of compact and high-density circuit designs.

Applications

The versatility of the PI3B33X257BE makes it a prime choice for a multitude of applications, including:

• Switching on/off signals in networking equipment such as routers and switches.
• Bus isolation in servers and data storage devices to maintain signal integrity.
• Interfacing between different logic levels in mixed-voltage systems.
• Signal gating in audio/video equipment for consumer electronics.

Diodes Incorporated's PI3B33X257BE is engineered to deliver high performance, reliability, and ease of integration, making it a go-to solution for designers looking to enhance their system's signal routing capabilities with minimal impact on signal quality and power efficiency.
