The SBR12U100P5-13 is a high-performance Super Barrier Rectifier (SBR) from Diodes Incorporated, designed to offer superior performance in a variety of applications. This rectifier is particularly well-suited for use in low voltage, high frequency inverters, free-wheeling, and polarity protection applications. With its cutting-edge super barrier technology, it provides a low forward voltage drop and high surge current capability.

Key Features

• Low Power Loss, High Efficiency: The SBR12U100P5-13 is optimized for minimal power loss, which translates to high efficiency in your electronic circuits. This is particularly important for power-sensitive applications.
• High Surge Capability: With its robust construction, this rectifier can withstand high surge currents, ensuring reliability and longevity even under stressful conditions.
• Low Forward Voltage Drop: The device boasts a low forward voltage drop, which helps to reduce thermal stress and improve overall system efficiency.
• Patented Super Barrier Rectifier Technology: The SBR technology used in this rectifier provides superior performance compared to traditional Schottky diodes, especially in terms of forward voltage and leakage current characteristics.
• Lead-Free Finish: The SBR12U100P5-13 is environmentally friendly with a lead-free finish, making it compliant with current RoHS directives.
• PowerDI®5 Package: Its compact PowerDI®5 package ensures a small footprint on the PCB, providing space-saving benefits without compromising on power handling capabilities.

Applications

The versatile nature of the SBR12U100P5-13 makes it an excellent choice for a wide range of applications, including:

• Switching power supplies
• Adapters
• Lighting applications
• Reverse battery protection
• DC-DC converters
• Automotive applications

Technical Specifications

The SBR12U100P5-13 operates with a repetitive peak reverse voltage of 100V and a forward continuous current of 12A, making it suitable for high-power applications. Its operating junction temperature range is from -55°C to 150°C, which ensures stable performance across a wide range of environmental conditions.

For engineers and designers looking for a rectifier that offers both efficiency and reliability, the SBR12U100P5-13 from Diodes Incorporated is an excellent choice that does not disappoint.
