The SMAZ5V1 is a robust voltage regulator diode designed and manufactured by Diodes Incorporated, a leading global provider of discrete, logic, analog, and mixed-signal semiconductors. This product is specifically engineered to provide precise voltage regulation and is ideal for a wide range of electronic applications.

Key Features

• Zener Voltage (V<sub>Z): The SMAZ5V1 offers a nominal Zener voltage of 5.1V, making it suitable for applications that require a regulated voltage close to 5V.
• Power Dissipation: With a power dissipation capability of 1W, this Zener diode can handle significant power levels, making it suitable for high-power applications.
• Package: The diode comes in a surface-mount SMA package, which is known for its compact footprint and ease of integration into a variety of circuit designs.
• Thermal Stability: It features excellent stability over a wide temperature range, ensuring reliable performance under varying environmental conditions.
• Low Leakage Current: The SMAZ5V1 is designed with a low leakage current, thereby increasing the efficiency of the device and reducing power loss.

Applications

The SMAZ5V1 is versatile and can be used in numerous applications, including:

• Voltage regulation modules
• Overvoltage protection circuits
• Power supply circuits
• Consumer electronics
• Telecommunication devices

Quality and Reliability

Diodes Incorporated is committed to delivering high-quality products. The SMAZ5V1 is built to meet stringent quality standards, ensuring reliability and performance. It is also RoHS compliant, reflecting the company's dedication to environmental responsibility.

Technical Specifications

Parameter Value Zener Voltage (V<sub>Z) 5.1V Power Dissipation 1W Package SMA Operating Temperature Range -55°C to +150°C

For detailed specifications and application support, it is recommended to consult the datasheet provided by Diodes Incorporated and contact their technical support team for any further inquiries.
