FWP-100A Real Image
Same model may have multiple batches, images only for reference.

FWP-100A

Part No FWP-100A
Manufacturer Eaton Bussmann
Catalog Electrical, Specialty Fuses
Description FUSE CARTRIDGE 100A 700VAC/VDC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Electrical, Specialty Fuses
Mfr Eaton Bussmann
Series FWP
Package Bulk
Product Status Active
Fuse Type Cartridge
Current Rating (Amps) 100A
Voltage Rating - AC 700 V
Voltage Rating - DC 700 V
Applications Electrical, Industrial
Approval Agency CE, CSA, UR
Breaking Capacity @ Rated Voltage 200kA AC, 50kA DC
Melting I2t 540
Standard Package 5 pcs
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.10.0040
Win Source Part Number 872434-FWP-100A
Ultra Librarian 3D Model Ultra Librarian FWP-100A CAD Model

Description

The FWP-100A is a specialty fuse designed for electrical and industrial applications. It features a cartridge fuse type.

  • Voltage Rating (AC): 700V
  • Voltage Rating (DC): 700V
  • Breaking Capacity (AC): 200kA
  • Breaking Capacity (DC): 50kA
  • Melting I2t: 540
  • Package: Bulk
  • Manufacturer: Eaton Bussmann
  • Series: FWP
  • Current Rating: 100A
  • Approvals: CE, CSA, and UR
  • Product Status: Active
