WCL3225-6R8-R Real Image
Same model may have multiple batches, images only for reference.

WCL3225-6R8-R

Part No WCL3225-6R8-R
Manufacturer Eaton Bussmann
Catalog Fixed Inductors
Description FIXED IND 6.8UH 310MA 1.5OHM SMD / 6.8 µH Unshielded Drum Core, Wirewound Inductor 310 mA 1.5Ohm Max Nonstandard
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Eaton - Electronics Division
Series WCL3225
Package Tape & Reel
Type Drum Core, Wirewound
Material - Core Ceramic
Inductance 6.8 µH
Tolerance ±5%
Current Rating (Amps) 310 mA
Shielding Unshielded
DC Resistance (DCR) 1.5Ohm Max
Q @ Freq 12 @ 7.96MHz
Frequency - Self Resonant 35MHz
Temperature Range - Operating -40°C ~ 85°C
Inductance Frequency - Test 7.96 MHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.138" L x 0.114" W (3.50mm x 2.90mm)
Height - Seated (Max) 0.089" (2.25mm)
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.50.8000
Other Names 283-WCL3225-6R8-RDKR,283-WCL3225-6R8-RCT,283-WCL3225-6R8-RTR
Standard Package 2,000
Win Source Part Number 1171197-WCL3225-6R8-R
Ultra Librarian 3D Model Ultra Librarian WCL3225-6R8-R CAD Model

Description

The Eaton WCL3225-6R8-R fixed inductor is a drum core, wirewound type with a nonstandard package/case.

  • Core Type: drum core, wirewound
  • Package/Case: nonstandard
  • Core Material: ceramic
  • Tolerance: ±5%
  • Height: 0.089" (2.25mm)
  • Dimension: 0.138" L x 0.114" W (3.50mm x 2.90mm)
  • Q @ Freq: 12 @ 7.96MHz
  • Frequency Self-Resonant: 35MHz
