The EL2082CS is a dual, high-speed, low-power operational amplifier manufactured by Elantec (later acquired by Intersil, then Renesas). As an end-of-life product, it was designed for applications that require wide bandwidth and fast settling time with minimal power consumption. The dual amplifier configuration allows for efficient use of board space and reduced component count.

Applications

• Video amplifiers
• Cable drivers
• High-speed data acquisition systems
• Pulse amplifiers
• ADC/DAC buffers

Features

• Dual operational amplifier in a single package
• High slew rate (typically several hundred V/µs)
• Wide bandwidth (typically several hundred MHz)
• Low power consumption
• Low differential gain and phase

Benefits

• Space saving with dual amplifier configuration
• Accurate amplification of high-frequency signals
• Fast settling time for improved system response
• Reduced power consumption for portable applications

Additional Details

The EL2082CS is commonly available in a surface-mount package, such as SOIC. It requires bypass capacitors for stable operation. Due to its end-of-life status, sourcing the EL2082CS might pose challenges. The EL2082CS provided engineers with a reliable, high-performance solution for a variety of signal processing requirements, particularly where power efficiency and speed are critical. Designers should refer to the datasheet for precise electrical characteristics and application recommendations.
