B78108S1223K Real Image
Same model may have multiple batches, images only for reference.

B78108S1223K

Part No B78108S1223K
Manufacturer EPCOS (TDK)
Catalog Fixed Inductors
Description Ind RF Choke Bobbin Core 22uH 10% 100KHz 55Q-Factor Ferrite 560mA AXL T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting SMD (SMT)
Case / Package Axial
Contact Plating Tin
Core Material Ferrite
Current Rating 560 mA
DC Current 560 mA
DC Resistance (DCR) 740 mΩ
Diameter 4 mm
Inductance 22 µH
Inductance Tolerance 10 %
Lead/Base Style Axial
Lead Free Yes
Lead Length 25 mm
Length 11.5 mm
Max DC Current 560 mA
Military Standard Not
Number of Pins 2
Packaging Tape & Reel (TR)
Q Factor 55
Radiation Hardening No
REACH SVHC No SVHC
Resistance 740 mΩ
RoHS Compliant
Schedule B 8504500000, 8504500000
Self Resonant Frequency 13 MHz
Shielding Unshielded
Test Frequency 100 kHz
Tolerance 10 %
Win Source Part Number 1089613-B78108S1223K
Categories Fixed Inductors
Manufacturer EPCOS (TDK)
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian B78108S1223K CAD Model

Description

This fixed inductor from EPCOS (TDK) is an unshielded SMD (SMT) component with 2 pins, measuring 11.5 mm in length and 4 mm in diameter.

  • Type: Unshielded SMD (SMT)
  • Pins: 2
  • Length: 11.5 mm
  • Diameter: 4 mm
  • Inductance: 22 µH
  • Tolerance: 10%
  • DC Resistance (DCR): 740 mΩ
  • Maximum DC Current: 560 mA
  • Lead-Free: Yes
  • RoHS Compliant: Yes
