The SG-615P 3.6864MC is a crystal oscillator manufactured by Epson. This oscillator is designed to provide a stable and accurate clock signal at a frequency of 3.6864 MHz. It's commonly used in various electronic devices that require a precise timing source for their operation. The SG-615P series is known for its compact size and reliability.

Applications

• Microcontrollers
• Communication devices
• Real-time clocks (RTC)
• Consumer electronics
• Industrial control systems

Features

• Frequency: 3.6864 MHz
• Stability: ±50 ppm
• Operating Temperature: -20°C to +70°C
• Supply Voltage: 3.3V
• Output Waveform: CMOS
• Package: SMD

Benefits

• Precise Timing: Provides a stable and accurate clock signal for reliable system operation.
• Compact Size: Small SMD package allows for space-saving design in electronic devices.
• Wide Operating Temperature Range: Suitable for use in a variety of environmental conditions.
• Low Power Consumption: Helps to extend battery life in portable devices.
• Easy Integration: Compatible with standard CMOS logic levels for easy integration into electronic circuits.

Technical Specifications

The SG-615P 3.6864MC operates on a supply voltage of 3.3V and offers a frequency stability of ±50 ppm over its operating temperature range of -20°C to +70°C. The output waveform is CMOS, which is compatible with most digital logic circuits. The package type is SMD (Surface Mount Device), which is suitable for automated assembly processes. The oscillator provides a stable and reliable timing signal for various electronic applications. The start-up time is typically very short.
