FDC602P Real Image FDC602P real image4011
Same model may have multiple batches, images only for reference.
FDC602P Real Image FDC602P real image4011
FDC602P Real Image FDC602P real image4011
Same model may have multiple batches, images only for reference.

FDC602P

Part No FDC602P
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 20V 5.5A SSOT-6
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 5.5A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
Gate-Source Threshold Voltage 1.5V @ 250μA
Max Gate Charge 20nC @ 4.5V
Max Input Capacitance 1456pF @ 10V
Maximum Gate-Source Voltage ±12V
Power Dissipation (Max) 1.6W (Ta)
Maximum Rds On at Id,Vgs 35 mOhm @ 5.5A, 4.5V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SuperSOT-6
Dimension SOT-23-6 Thin, TSOT-23-6
Win Source Part Number 001125-FDC602P
Family Name FDC602P
Introduction Date December 20, 1999
ECCN EAR99
Country of Origin Israel, Philippines
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Industrial
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian FDC602P CAD Model

Description

FDC602P

The FDC602P is a versatile P-channel MOSFET known for its superior efficiency and performance. It is an excellent choice for various consumer electronics and communication devices due to its ability to manage power effectively.

  • Applications:
    • Smartphones and tablets
    • Consumer electronics
    • Communication devices
  • Features and Benefits:
    • Optimized for low power consumption
    • Compact size for integration in space-constrained devices
    • Fast switching speeds improve performance

Additional Details: The FDC602P is highly regarded for its power efficiency and compact design, making it ideal for portable devices where space and battery life are critical.
