Same model may have multiple batches, images only for reference.

FDS6990A

Name: FDS6990A
Brand: Fairchild/ON Semiconductor
SKU: 129920
Availability: InStock
Rating: 4.84 (97 reviews)

Get a Quote

Part No	FDS6990A
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET N-CH 30V 7.5A 8-Pin SOIC T/R / MOSFET 2N-CH 30V 7.5A 8SOIC
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
FET Type	2 N-Channel (Dual)
FET Feature	Logic Level Gate
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	7.5A
Maximum Rds On at Id,Vgs	22 mOhm @ 7.5A, 10V
Gate-Source Threshold Voltage	3V @ 1mA
Max Gate Charge	14nC @ 5V
Max Input Capacitance	550pF @ 15V
Maximum Power Dissipation	900mW
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Win Source Part Number	094101-FDS6990A
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Application Field	Used in Industrial, Power Management
Quantity per package	2,500
Family Name	FDS6990A
Introduction Date	June 10, 1999
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian FDS6990A CAD Model

Description

The Fairchild/ON Semiconductor FDS6990A is a dual N-Channel MOSFET commonly used in industrial and power management applications.

Drain-Source Breakdown Voltage: 30V
Continuous Drain Current (25°C): 7.5A
Maximum Rds On: 22 mOhm @ 7.5A and 10V
Maximum Input Capacitance: 550pF @ 15V
Maximum Gate-Source Voltage: ±20V
Operating Temperature: -55°C to 150°C
Power Dissipation: 900mW
Package Type: 8-SO
Mounting: SMD (SMT)
