FGH40N60SMD Fairchild/ON Semiconductor FGH40N60SMD Real Image FGH40N60SMD real image4175
Same model may have multiple batches, images only for reference.
FGH40N60SMD Fairchild/ON Semiconductor FGH40N60SMD Real Image FGH40N60SMD real image4175
FGH40N60SMD Fairchild/ON Semiconductor FGH40N60SMD Real Image FGH40N60SMD real image4175
Same model may have multiple batches, images only for reference.

FGH40N60SMD

Part No FGH40N60SMD
Manufacturer Fairchild/ON Semiconductor
Catalog IGBTs - Single
Description Trans IGBT Chip N-CH 600V 80A 349000mW 3-Pin(3+Tab) TO-247 Tube / IGBT 600V 80A 349W TO-247-3
Datasheet
FGH40N60SMD Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
IGBT Type Field Stop
VCEO Maximum Collector-Emitter Breakdown Voltage 600V
Maximum Current Collector 80A
Pulsed Collector Current 120A
Collector-emitter saturation voltage(Max) 2.5V @ 15V, 40A
Maximum Power Dissipation 349W
Total Switching Energy(Ets) 920μJ (on), 300μJ (off)
Input Type Standard
Gate Charge 180nC
Turn-on and Turn-off delay time 18ns/110ns
Testing Conditions 400V, 40A, 6 Ohm, 15V
Reverse Recovery Time (trr) 47ns
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-247-3
Win Source Part Number 001171-FGH40N60SMD
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 450
Family Name FGH40N60SMD
Introduction Date November 26, 2010
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian FGH40N60SMD CAD Model

Description

The FGH40N60SMD electronic component is a product manufactured by Fairchild/ON Semiconductor. The supply and demand status of this product is balanced.

  • Type: IGBT, Field Stop
  • Collector-Emitter Breakdown Voltage: 600V
  • Current Collector (Max): 80A
  • Power Dissipation (Max): 349W
  • RoHS Compliant: Yes
  • Halogen-Free: Yes
