FSUSB42UMX Real Image FSUSB42UMX real image4270 FSUSB42UMX real image4271 FSUSB42UMX real image4272
Same model may have multiple batches, images only for reference.
FSUSB42UMX Real Image FSUSB42UMX real image4270 FSUSB42UMX real image4271 FSUSB42UMX real image4272
FSUSB42UMX Real Image FSUSB42UMX real image4270 FSUSB42UMX real image4271 FSUSB42UMX real image4272
Same model may have multiple batches, images only for reference.

FSUSB42UMX

Part No FSUSB42UMX
Manufacturer Fairchild/ON Semiconductor
Catalog Interface - Analog Switches - Special Purpose
Description IC USB SWITCH DPDT 10UMLP
Datasheet
FSUSB42UMX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Applications USB
Switch Circuit DPDT
Number of Channels 1
Max On Resistance 6.5 Ohm
Single Supply Voltage (V+) 2.4 V to 4.4 V
-3db Bandwidth 720MHz
Features Break-Before-Make, USB 2.0
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 10-UMLP (1.8x1.4)
Win Source Part Number 016559-FSUSB42UMX
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name FSUSB42
Introduction Date June 01, 2007
ECCN EAR99
Country of Origin Philippines, Thailand
Halogen Free Compliant
Estimated EOL Date 2024
Quantity per package 5k pcs
Ultra Librarian 3D Model Ultra Librarian FSUSB42UMX CAD Model

Description

The Fairchild/ON Semiconductor 016559-FSUSB42UMX is an active DPDT switch circuit with a 720MHz -3db bandwidth.

  • Application: USB applications
  • Package: 10-UMLP (1.8x1.4)
  • Single Supply Voltage (V+): 2.4 V to 4.4 V
  • Dual Supply Voltage(V±): Not applicable
  • Popularity: High
  • Supply and Demand Status: Balanced
  • Package Contains: 5k pieces
