Same model may have multiple batches, images only for reference.

ACS724LLCTR-50AB-T

Name: ACS724LLCTR-50AB-T
Brand: Allegro MicroSystems, LLC
SKU: 847984
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	ACS724LLCTR-50AB-T
Manufacturer	Allegro MicroSystems, LLC
Catalog	Current Transducers
Description	SENSOR CURRENT HALL
Datasheet	ACS724LLCTR-50AB-T Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Sensors, Transducers - Current Sensors
Mfr	Allegro MicroSystems, LLC
Package	Tape & Reel
Product Status	Active
For Measuring	AC/DC
Sensor Type	Hall Effect, Open Loop
Current - Sensing	50A
Number of Channels	1
Output	Ratiometric, Voltage
Sensitivity	40mV/A
Frequency	DC ~ 120kHz
Linearity	±1.5%
Accuracy	±0.8%
Voltage - Supply	4.5V ~ 5.5V
Response Time	4µs
Current - Supply (Max)	14mA
Temperature Range - Operating	-40°C ~ 150°C
Polarization	Bidirectional
Mounting Type	Surface Mount
Package / Case	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package	8-SOIC
Base Product Number	ACS724
Standard Package	3,000 pcs
MSL Level	2 (1 Year)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.39.0001
Win Source Part Number	847984-ACS724LLCTR-50AB-T
Ultra Librarian 3D Model	Ultra Librarian ACS724LLCTR-50AB-T CAD Model

Alternative Products

Description

The ACS724LLCTR-50AB-T is a current sensor featuring a hall effect, open-loop sensor type from unspecified manufacturer.

Sensor Type: Hall Effect, Open-Loop
Sensitivity: 40mV/A
Current Measurement: AC and DC currents
Voltage Supply: 4.5V to 5.5V
Response Time: 4μs
Standard Package: 3,000 pieces
Applications: Current monitoring and control systems
Mounting Type: Surface Mount
Package: 8-SOIC
Operating Temperature: -40°C to 150°C
