MBR1020VL Real Image MBR1020VL real image MBR1020VL label picture
Same model may have multiple batches, images only for reference.
MBR1020VL Real Image MBR1020VL real image MBR1020VL label picture
MBR1020VL Real Image MBR1020VL real image MBR1020VL label picture
Same model may have multiple batches, images only for reference.

MBR1020VL

Part No MBR1020VL
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 20V 1A SOD123F
Datasheet
MBR1020VL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 20V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 340mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 12.4ns
Current - Reverse Leakage @ Vr 600μA @ 20V
Mounting SMD (SMT)
Case / Package SOD-123F
Operating Temperature - Junction -55°C to 125°C
Win Source Part Number 1072386-MBR1020VL
Family Name MBR1020VL
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian MBR1020VL CAD Model

Description

The MBR1020VL is a Schottky diode from Fairchild/ON Semiconductor.

  • Maximum DC Reverse Voltage: 20V
  • Average Rectified Current: 1A
  • Maximum Forward Voltage: 340mV @ 1A
  • Reverse Recovery Time: 12.4ns
  • Package: SOD-123F
  • Mounting: SMD (SMT)
  • Popularity: high
  • Supply and Demand Status: sufficient
  • Estimated EOL Date: 2024
  • Halogen-Free: compliant
