MMBT3904

Name: MMBT3904
Brand: Fairchild/ON Semiconductor
SKU: 235298
Availability: InStock
Rating: 4.91 (566 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	MMBT3904
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors (BJT) - Single
Description	TRANS NPN 40V 0.2A SOT-23
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Fairchild Semiconductor
Standard Package	1
Category	Discrete Semiconductor Products
Family	Transistors (BJT) - Single
Packaging	Reel
Transistor Type	NPN
Current - Collector (Ic) (Max)	200mA
Voltage - Collector Emitter Breakdown (Max)	40V
Vce Saturation (Max) @ Ib Ic	300mV @ 5mA 50mA
DC Current Gain (hFE) (Min) @ Ic Vce	100 @ 10mA 1V
Power - Max	350mW
Frequency - Transition	300MHz
Mounting Style	SMD/SMT
Package	TO-236-3 SC-59 SOT-23-3
Manufacturer Device Package	SOT-23
Catalog	NPN Transistors
Win Source Part Number	096077-MMBT3904
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Application Field	Used in Industrial, Power Management
Family Name	MMBT3904
Introduction Date	May 13, 2002
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2024
Package	Tape & Reel (TR);Cut Tape (CT)
Product Status	Active
Vce Saturation (Max) @ Ib, Ic	300mV @ 5mA, 50mA
Current - Collector Cutoff (Max)	50nA
DC Current Gain (hFE) (Min) @ Ic, Vce	100 @ 10mA, 1V
Operating Temperature	-55°C ~ 150°C (TJ)
Grade	-
Mounting Type	Surface Mount
Package / Case	TO-236-3, SC-59, SOT-23-3
Supplier Device Package	SOT-23-3 (TO-236)
Ultra Librarian 3D Model	Ultra Librarian MMBT3904 CAD Model

Alternative Products

Description

The Fairchild Semiconductor MMBT3904 is an NPN transistor with a power max of 350mW and a voltage collector emitter breakdown of 40V.

Power max: 350mW
Voltage collector emitter breakdown: 40V
Frequency transition: 300MHz
Vce saturation: 300mV
Product type: single-circuit discrete semiconductor
Package: TO-236-3 SC-59 SOT-23-3
Mounting: SMD/SMT
Suitable for: use in various electronic applications
Popularity: high
