MMSZ5240B Real Image MMSZ5240B real image3514
Same model may have multiple batches, images only for reference.
MMSZ5240B Real Image MMSZ5240B real image3514
MMSZ5240B Real Image MMSZ5240B real image3514
Same model may have multiple batches, images only for reference.

MMSZ5240B

Part No MMSZ5240B
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes - Zener - Single
Description DIODE ZENER 10V 500MW SOD123
Datasheet
MMSZ5240B Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Voltage - Zener (Nom) (Vz) 10V
Tolerance ±5%
Maximum Power Dissipation 500mW
Impedance (Max) (Zzt) 17 Ohm
Current - Reverse Leakage @ Vr 3μA @ 8V
Voltage - Forward (Vf) (Max) @ If 900mV @ 10mA
Temperature Range - Operating -55°C to 150°C
Mounting SMD (SMT)
Case / Package SOD-123
Win Source Part Number 059240-MMSZ5240B
Ultra Librarian 3D Model Ultra Librarian MMSZ5240B CAD Model

Description

The MMSZ5240B is a Zener diode from ON Semiconductor.

  • Voltage - Zener (Nom) (Vz): 10V
  • Tolerance: ±5%
  • Maximum Forward Voltage (Vf) @ If: 900mV @ 10mA
  • Current - Reverse Leakage @ Vr: 3μA @ 8V
  • Impedance (Max) (Zzt): 17 Ohm
  • Popularity: popular
  • Category: Discrete Semiconductor Products
  • Operating Temperature Range: -55°C to 150°C
  • Package: SOD-123
  • Maximum Power Dissipation: 500mW
