MOC3061SR2M Fairchild/ON Semiconductor MOC3061SR2M Real Image MOC3061SR2M Real Image1 MOC3061SR2M Real Image2
Same model may have multiple batches, images only for reference.
MOC3061SR2M Fairchild/ON Semiconductor MOC3061SR2M Real Image MOC3061SR2M Real Image1 MOC3061SR2M Real Image2
MOC3061SR2M Fairchild/ON Semiconductor MOC3061SR2M Real Image MOC3061SR2M Real Image1 MOC3061SR2M Real Image2
Same model may have multiple batches, images only for reference.

MOC3061SR2M

Part No MOC3061SR2M
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Triac, SCR Output
Description Triac AC-OUT 1-CH 600V 6-Pin PDIP SMD T/R / OPTOISOLATOR 4.17KV TRIAC 6SMD
Datasheet
MOC3061SR2M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Output Type Triac
Zero Crossing Circuit Yes
Number of Channels 1
Isolation Voltage 4170Vrms
Voltage - Off State 600V
Static dV/dt (Min) 600V/μs
Current - LED Trigger (Ift) (Max) 15mA
Current - Hold (Ih) 500μA (Typ)
Forward Voltage 1.3V
Continuous forward current- Max 60mA
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 6-SMD
Approvals UL
Win Source Part Number 024190-MOC3061SR2M
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 1k pcs
Family Name MOC3061M
Introduction Date May 29, 2003
ECCN EAR99
Country of Origin Republic of Korea, Thailand
Halogen Free Not Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian MOC3061SR2M CAD Model

Description

The Fairchild/ON Semiconductor MOC3061SR2M is a triac output type isolator with an off-state voltage of 600V and an isolation voltage of 4170Vrms.

  • Current Hold: 500μA
  • Static dV/dt: 600V/μs
  • Current LED Trigger: 15mA
  • Operating Temperature: -40°C to 85°C
  • Package: 6-SMD
  • Popularity: High
  • Supply and Demand Status: Sufficient
  • Quantity per Package: 1k pcs
