NC7S00M5X Real Image NC7S00M5X Real Image1 NC7S00M5X Real Image2 NC7S00M5X Real Image3 NC7S00M5X Real Image4
Same model may have multiple batches, images only for reference.
NC7S00M5X Real Image NC7S00M5X Real Image1 NC7S00M5X Real Image2 NC7S00M5X Real Image3 NC7S00M5X Real Image4
NC7S00M5X Real Image NC7S00M5X Real Image1 NC7S00M5X Real Image2 NC7S00M5X Real Image3 NC7S00M5X Real Image4
Same model may have multiple batches, images only for reference.

NC7S00M5X

Part No NC7S00M5X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC GATE NAND 1CH 2-INP SOT-23-5
Datasheet
NC7S00M5X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type NAND Gate
Number of Circuits 1
Number of Inputs 2
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 1μA
Current - Output High, Low 2.6mA, 2.6mA
Logic Level - Low 0.5V
Logic Level - High 1.5V
Max Propagation Delay @ V, Max CL 17ns @ 6V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Dimension SC-74A, SOT-753
Win Source Part Number 024725-NC7S00M5X
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name NC7S00
Introduction Date June 07, 2000
ECCN EAR99
Country of Origin China, Philippines
Halogen Free Compliant
Estimated EOL Date 2024
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian NC7S00M5X CAD Model

Description

The Fairchild/ON Semiconductor NC7S00M5X is a NAND gate logic type integrated circuit that has 2 inputs and 1 circuit.

  • Maximum Propagation Delay @ V, Max CL: 17ns @ 6V, 50pF
  • Current - Quiescent (max): 1μA
  • Current - Output High: 2.6mA
  • Current - Output Low: 2.6mA
  • Logic Level - Low: 0.5V
  • Logic Level - High: 1.5V
  • Temperature Range: -40°C to 85°C
  • Supply Voltage: 2 V to 6 V
  • Package: SOT-23-5
  • Popularity: High
  • Supply and Demand Status: Balanced
  • Package Quantity: 3k pcs
