PZTA42 Real Image PZTA42 Real Image
Same model may have multiple batches, images only for reference.
PZTA42 Real Image PZTA42 Real Image
PZTA42 Real Image PZTA42 Real Image
Same model may have multiple batches, images only for reference.

PZTA42

Part No PZTA42
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description Trans GP BJT NPN 300V 0.5A 1000mW 4-Pin(3+Tab) SOT-223 T/R / TRANS NPN 300V 0.5A SOT-223
Datasheet
PZTA42 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Transistor Polarity NPN
Maximum Current Collector 500mA
VCEO Maximum Collector-Emitter Breakdown Voltage 300V
Max Vce (sat) 500mV @ 2mA, 20mA
Collector Cut-off Current(Max) 100nA (ICBO)
Typical Gain (hFE) (Min) 40 @ 30mA, 10V
Maximum Power Dissipation 1W
Frequency - Transition 50MHz
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-223-4
Win Source Part Number 062252-PZTA42
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 4k pcs
Family Name PZTA42
Introduction Date June 08, 1998
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian PZTA42 CAD Model

Description

The Fairchild/ON Semiconductor PZTA42 is an NPN transistor that is used in various electronic applications.

  • Maximum Collector-Emitter Breakdown Voltage: 300V
  • Maximum Power Dissipation: 1W
  • Supply and Demand Status: Balance, which means that it is neither too difficult nor too easy to find in the market.
  • Component Status: An active component and is still widely used in various electronic applications.
  • Reliability: A reliable component that can be used in various electronic applications.
