TIP31C Fairchild/ON Semiconductor TIC116MS real image TIP31C Real Image
Same model may have multiple batches, images only for reference.
TIP31C Fairchild/ON Semiconductor TIC116MS real image TIP31C Real Image
TIP31C Fairchild/ON Semiconductor TIC116MS real image TIP31C Real Image
Same model may have multiple batches, images only for reference.

TIP31C

Part No TIP31C
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors (BJT) - Single
Description TRANS NPN 100V 3A TO220AB / Trans GP BJT NPN 100V 3A 2000mW 3-Pin(3+Tab) TO-220 Bag
Datasheet
TIP31C Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Tube/Rail
Status Active
Transistor Polarity NPN
Maximum Current Collector 3A
VCEO Maximum Collector-Emitter Breakdown Voltage 100V
Max Vce (sat) 1.2V @ 375mA, 3A
Collector Cut-off Current(Max) 300μA
Typical Gain (hFE) (Min) 10 @ 3A, 4V
Maximum Power Dissipation 2W
Frequency - Transition 3MHz
Temperature Range - Operating -65°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Win Source Part Number 093853-TIP31C
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial
Family Name TIP31C
Introduction Date January 01, 2003
ECCN EAR99
Country of Origin China, Republic of Korea, United States of America
Halogen Free Not Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian TIP31C CAD Model

Description

The TIP31C is an NPN transistor manufactured by ON Semiconductor.

  • Maximum Current Collector: 3A
  • VCEO maximum collector-emitter breakdown voltage: 100V
  • Maximum Vce (sat): 1.2V @ 375mA, 3A
  • Collector cut-off current (max): 300μA
  • Typical gain (hFE) (min): 10 @ 3A, 4V
  • Maximum power dissipation: 2W
