KBU1004 GeneSiC Semiconductor
Same model may have multiple batches, images only for reference.

KBU1004

Part No KBU1004
Manufacturer GeneSiC Semiconductor
Catalog Bridge Rectifiers
Description 10A BRIDGE RECTIFIER | BRIDGE RECT 1PHASE 400V 10A KBU
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer GeneSiC Semiconductor
Packaging Bulk
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Maximum) 400V
Current - Average Rectified (Io) 10A
Voltage - Forward (Vf) (Maximum) at If 1.05V at 10A
Current - Reverse Leakage at Vr 10μA at 400V
Temperature Range - Operating -55°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package 4-SIP, KBU
Supplier Device Package KBU
Manufacturer Pack Quantity 300
MSL Level 1 (Unlimited)
Win Source Part Number 1192725-KBU1004
Manufacturer Homepage www.wontop.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian KBU1004 CAD Model

Description

The KBU1004 from GeneSiC Semiconductor is a single phase diode with a peak reverse voltage of 400 V and an average rectified current of 10 A.

  • Peak Reverse Voltage: 400 V
  • Average Rectified Current: 10 A
  • Forward Voltage: 1.05 V @ 10 A
  • Reverse Leakage Current: 10 μA @ 400 V
  • Package: 4-SIP, KBU
  • Operating Temperature Range: -55°C to 150°C
