3.0SMCJ20A MDE Semiconductor, Inc.
Same model may have multiple batches, images only for reference.

3.0SMCJ20A

Part No 3.0SMCJ20A
Manufacturer GOOD-ARK Electronics
Catalog TVS - Diodes
Description TVS, UNI-DIR, 3000W, 20V, DO-214
Datasheet
3.0SMCJ20A Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr GOOD-ARK Electronics
Series 3.0SMCJx
Package Tape & Reel
Product Status Active
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 20V
Voltage - Breakdown (Min) 22.2V
Voltage - Clamping (Max) @ Ipp 32.4V
Current - Peak Pulse (10/1000µs) 92.6A
Power - Peak Pulse 3000W (3kW)
Power Line Protection No
Applications General Purpose
Temperature Range - Operating -65°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Supplier Device Package DO-214AB (SMC)
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 815533-3.0SMCJ20A
Ultra Librarian 3D Model Ultra Librarian 3.0SMCJ20A CAD Model

Description

The 815533-3.0SMCJ20A series Zener diode, is a surface mount circuit protection component used for transient voltage suppression.

  • Reverse Standoff Voltage: 20V
  • Breakdown Voltage: 22.2V
  • Clamping Voltage: 32.4V @ peak pulse current of 92.6A
  • Peak Pulse Power: 3000W (3kW)
  • Package: DO-214AB (SMC)
  • Packaging: Tape and Reel
  • Standard Package: 3,000 pieces
  • Temperature Range: -65°C to 150°C (TJ)
  • Manufacturer: GOOD-ARK Electronics
