The S1336-8BK is a silicon PIN photodiode manufactured by Hamamatsu. It is designed for high-sensitivity light detection in the visible to near-infrared spectral range. The photodiode features a large active area and low dark current, making it suitable for various applications requiring precise light measurement.

Applications

• Optical Encoders
• Light Meters
• Analytical Instruments
• Bar Code Readers
• Medical Devices

Features

• High Sensitivity: Detects weak light signals with high accuracy.
• Large Active Area: Provides a wide target area for light collection.
• Low Dark Current: Minimizes noise and improves signal-to-noise ratio.
• Wide Spectral Response: Sensitive to light in the visible to near-infrared range.
• Fast Response Time: Enables detection of rapidly changing light signals.

Benefits

• Accurate Light Measurement: High sensitivity and low dark current ensure precise light measurement.
• Improved Signal-to-Noise Ratio: Low dark current minimizes noise, improving the signal-to-noise ratio.
• Versatile Applications: Suitable for a wide range of applications requiring light detection.
• Reliable Performance: Hamamatsu's quality ensures reliable and consistent performance.

Technical Specifications

• Active Area: Typically around 3.6 x 3.6 mm
• Spectral Response: 320 nm to 1100 nm
• Peak Sensitivity Wavelength: Typically around 960 nm
• Dark Current: Typically less than 1 nA
• Reverse Voltage: Up to 30 V
• Capacitance: Typically around 5 pF

The S1336-8BK offers excellent performance for demanding light detection applications. For specific details and application notes, consult the manufacturer's datasheet.
