Part No 104B
Manufacturer Hammond Manufacturing
Catalog Audio Transformers
Description AUDIO XFMR 150 / 80K TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Impedance - Primary (Ohms) 150
Impedance - Secondary (Ohms) 80k
DC Resistance (DCR) - Primary 6.6Ohm
DC Resistance (DCR) - Secondary 3.73kOhm
Transformer Type Miniature Epoxy Potted
Frequency Range 60Hz
Frequency Response -1dB
Voltage - Isolation 200V
Insertion Loss 1dB
Power Level 5mW
Mounting Type Through Hole
Size / Dimension 0.860" L x 0.710" W (21.84mm x 18.03mm)
Height - Seated (Max) 0.750" (19.05mm)
Termination Style PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1510547-104B
Ultra Librarian 3D Model Ultra Librarian 104B CAD Model

Description
