D44E1 New Jersey Semi-Conductor Products, Inc.
Same model may have multiple batches, images only for reference.

D44E1

Part No D44E1
Manufacturer Harris Corporation
Catalog Transistors (BJT) - Single
Description TRANS NPN DARL 40V 10A TO220
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - Bipolar (BJT) - Single Bipolar Transistors
Mfr Harris Corporation
Package Bulk
Product Status Active
Transistor Type NPN - Darlington
Current - Collector (Ic) (Max) 10 A
Voltage - Collector Emitter Breakdown (Max) 40 V
Vce Saturation (Max) @ Ib, Ic 2V @ 20mA, 10A
Current - Collector Cutoff (Max) 10µA
DC Current Gain (hFE) (Min) @ Ic, Vce 1000 @ 5A, 5V
Power - Max 1.67 W
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 583494-D44E1
Ultra Librarian 3D Model Ultra Librarian D44E1 CAD Model

Description

The 583494-D44E1 is a single bipolar transistor designed for general-purpose switching and amplification applications.

  • Manufacturer: Harris Corporation
  • Type: discrete semiconductor products
  • Maximum Power Dissipation: 1.67W
  • Maximum Collector-Emitter Breakdown Voltage: 40V
  • Maximum Collector Current: 10A
  • Saturation Voltage: 2V @ 20mA and 10A
  • DC Current Gain: 1000 @ 5A and 5V
  • Package: TO-220-3 package
  • Temperature Range: -55°C to 150°C
  • Component Type: active component
  • Application: commonly used in various electronic systems that require high-power switching and amplification.
