RFP10P12 GE Solid State
Same model may have multiple batches, images only for reference.

RFP10P12

Part No RFP10P12
Manufacturer Harris Corporation
Catalog Transistors - FETs, MOSFETs - RF
Description P-CHANNEL POWER MOSFET
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr Harris Corporation
Package Bulk
Product Status Active
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 120 V
Current - Continuous Drain (Id) @ 25°C 10A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 500mOhm @ 5A, 10V
Vgs(th) (Max) @ Id 4V @ 1mA
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 1700 pF @ 25 V
Power Dissipation (Max) 75W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Supplier Device Package TO-220
Package / Case TO-220-3
Standard Package 300 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 660096-RFP10P12
Ultra Librarian 3D Model Ultra Librarian RFP10P12 CAD Model

Description

The RFP10P12 is an N-channel MOSFET designed for various electronic applications.

  • Type: standard MOSFET
  • Drain to Source Voltage Rating: 120V
  • Continuous Drain Current: 10A
  • Usage: suitable for medium power applications.
  • On-Resistance: 500mOhm @ a current of 5A and a gate-source voltage of 10V
  • Gate Threshold Voltage: 4V
  • Control: can be easily controlled by a compatible gate driver.
  • Maximum Power Dissipation: 75W
  • Efficiency: ensuring efficient operation even @ moderate power levels.
  • Package: TO-220-3
  • Supply: supplied in bulk.
  • Status: active
  • Manufacturer: Harris Corporation
