The BM10SB(0.8)-24DP-0.4V is a compact, low-profile board-to-board connector manufactured by Hirose Electric Co Ltd. It is designed for high-density mounting in various electronic devices, particularly those requiring space-saving solutions. This connector offers reliable electrical connection in a small form factor, making it suitable for applications where miniaturization is critical.

Applications

• Smartphones and mobile devices connecting internal boards.
• Tablets and laptops for connecting display panels and other modules.
• Wearable devices like smartwatches and fitness trackers.
• Digital cameras and camcorders for connecting image sensors and processing boards.
• Medical devices such as portable monitors and diagnostic equipment.
• Industrial equipment requiring compact and reliable connections.

Features

• Number of Contacts: 24
• Pitch: 0.4mm
• Stacking Height: 0.8mm
• Double-row configuration
• Surface Mount Technology (SMT)
• High-speed transmission capability
• Secure locking mechanism
• RoHS Compliant

Benefits

• Space Saving: Ultra-compact design allows for high-density mounting.
• Reliable Connection: Ensures secure and stable electrical connection.
• High-Speed Data Transfer: Supports high-speed signal transmission.
• Easy Assembly: SMT design enables efficient automated assembly.
• Durable: Robust construction for long-term reliability.
• Versatile: Suitable for a wide range of applications.

Technical Specifications

Number of Contacts: 24
Pitch: 0.4mm
Stacking Height: 0.8mm
Voltage Rating: 50V AC/DC (Typical, check datasheet for exact value)
Current Rating: 0.3A per contact (Typical, check datasheet for exact value)
Operating Temperature: -40°C to +85°C (Typical, check datasheet for exact value)
Contact Material: Copper Alloy
Insulator Material: Thermoplastic
Mating Style: Board-to-Board
