Same model may have multiple batches, images only for reference.
FH42-23S-0.3SHW(10) Real Image
Same model may have multiple batches, images only for reference.

FH42-23S-0.3SHW(10)

Part No FH42-23S-0.3SHW(10)
Manufacturer Hirose Electric Co Ltd
Catalog Flat Flex Cables (FFC, FPC)
Description CONN FPC TOP 23POS 0.30MM R/A
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors
Estimated Pruduction Lead Time 25 Weeks
Features 23 Position FPC Connector Contacts, Top 0.012" (0.30mm) Surface Mount, Right Angle
Manufacturer Hirose Electric Co Ltd
Series FH42
Package Reel - TR
Operating Temperature Range -55°C ~ 85°C
Mounting Surface Mount, Right Angle
Family Name FH42
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4051
Quantity per package 5000
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 871952-FH42-23S-0.3SHW(10)
Ultra Librarian 3D Model Ultra Librarian FH42-23S-0.3SHW(10) CAD Model

Description

The FH42-23S-0.3SHW(10) is a 23 position FPC connector contact from Hirose Electric Co Ltd.

  • Product: 23 position FPC connector contact
  • Manufacturer: Hirose Electric Co Ltd
  • Mounting: Top 0.012" (0.30mm) surface mount
  • Mounting Style: Right-angle
  • Operating Temperature Range: -55°C ~ 85°C
  • Package: Reel-TR
  • Quantity per Package: 5000
