Same model may have multiple batches, images only for reference.
MDF76KBW-30S-1H(55) Real Image
Same model may have multiple batches, images only for reference.

MDF76KBW-30S-1H(55)

Part No MDF76KBW-30S-1H(55)
Manufacturer Hirose Electric Co Ltd
Catalog Circular Connectors - Housings
Description CONN RCPT 30P 0.039 GOLD SMD R/A / 30 Position Receptacle Connector 0.039" (1.00mm) Board Cutout, Surface Mount, Right Angle Gold
Datasheet
MDF76KBW-30S-1H(55) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr Hirose Electric Co Ltd
Series MDF76
Package Tape & Reel (TR)
Product Status Obsolete
Connector Type Receptacle
Contact Type Center Strip Contact
Style Board to Cable/Wire
Number of Positions 30
Number of Positions Loaded All
Pitch - Mating 0.039" (1.00mm)
Number of Rows 1
Mounting Type Board Cutout, Surface Mount, Right Angle
Termination Solder
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 12.0µin (0.30µm)
Insulation Color Beige
Temperature Range - Operating -40°C ~ 85°C
Material Flammability Rating UL94 V-0
Contact Finish - Post Tin
Features Solder Retention
Current Rating (Amps) Varies by Wire Gauge
Voltage Rating 200VAC
Applications General Purpose
Insulation Material Polyamide (PA), Nylon
Contact Material Phosphor Bronze
Contact Finish Thickness - Post 39.4µin (1.00µm)
Base Product Number MDF7
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names MDF76KBW30S1H55,*MDF76KBW-30S-1H(55),547-0606-9-55,H11696CT,H11696DKR,H11696TR,MDF76KBW-30S-1H(55)-ND
Standard Package 3,000
Win Source Part Number 990985-MDF76KBW-30S-1H(55)
Ultra Librarian 3D Model Ultra Librarian MDF76KBW-30S-1H(55) CAD Model

Description

The Hirose Electric Co Ltd MDF76 series is a rectangular connector that is designed for use with 30 center strip contacts. Bold the product name (e.g., BAV99S,135 → BAV99S,"135") and manufacturer (e.g., Nexperia USA Inc. → Nexperia USA Inc.).

  • Series: MDF76
  • Connector Type: Rectangular connector
  • Contacts: 30 center strip contacts
  • Connector Type: Receptacle
  • Mounting: Soldered to the board
  • Category: Board to cable/wire
  • Pitch: 0.039" (1.00mm)
  • Mounting Type: Surface mount
  • Temperature Range: -40°C ~ 85°C
  • HTSUS Code: 8536.69.4040
  • Packaging: Tape & reel
  • Standard Package: 3,000 connectors per package
