The I-PEX 20455-030E-12 is a Micro-Coaxial Cable Connector. These connectors are known for their compact size and reliable performance in high-frequency applications. The 20455 series is specifically designed for applications where space is limited and a secure connection is crucial.

Applications:

• LCD and LED Televisions: Used for internal connections between display panels and driver boards.
• Laptop Computers: Connects display panels, cameras, and other internal peripherals.
• Tablet Computers: Provides reliable connections within the compact design.
• Smartphones: Facilitates connections for displays and cameras.
• Navigation Systems: Used in GPS devices for display and camera connections.
• Medical Equipment: Employed in devices requiring high-density and reliable connections.
• Industrial Equipment: Integrated into control panels and monitoring systems.

Features:

• Micro-Coaxial Design: Ensures excellent signal integrity in high-frequency applications.
• Compact Size: Allows for use in devices with limited space.
• Secure Connection: Provides a reliable and stable connection, reducing the risk of signal loss or interruption.
• High-Density: Supports a large number of connections in a small area.
• RoHS Compliant: Meets environmental regulations for hazardous substances.
• Halogen-Free: Complies with standards for halogen-free materials.

Benefits:

• Improved Signal Integrity: The micro-coaxial design minimizes signal degradation, ensuring optimal performance.
• Space Savings: The compact size allows for integration into small devices, maximizing space utilization.
• Enhanced Reliability: The secure connection reduces the risk of connection failures, improving overall system reliability.
• Simplified Assembly: Designed for easy and efficient assembly, reducing manufacturing costs.
• Environmental Compliance: RoHS compliance ensures adherence to environmental regulations.
• Durability: Designed to withstand mechanical stress and environmental factors.

Additional Details:

The I-PEX 20455-030E-12 typically features a very fine pitch, enabling high-density connections. It is often used with corresponding I-PEX receptacles to form a complete connection solution. The connector is designed for automated assembly processes, ensuring consistent and reliable connections in mass production. It is crucial to use appropriate tools and handling procedures to avoid damage during assembly.

Electrical characteristics include a specified voltage rating, current rating, and impedance, which are critical for maintaining signal integrity in high-speed data transmission. The operating temperature range is usually specified to ensure reliable performance in various environmental conditions. Shielding is often incorporated into the design to minimize electromagnetic interference (EMI), further enhancing signal quality.
