The IDT74FCT821ATSO is a 10-bit bus interface register with D-type flip-flops, manufactured by Integrated Device Technology (IDT). It's part of the Fast CMOS Technology (FCT) family, designed for high-speed performance with low power consumption. This register is typically used for temporary storage and buffering of data on a bus system.
Applications:
- Bus Buffering: Provides buffering for data on a bus to increase drive capability and reduce signal degradation.
- Register Storage: Used as a register to temporarily store data for processing.
- Memory Interfacing: Employed in memory systems to store data being written to or read from memory.
- Peripheral Interfacing: Acts as an interface between a processor and peripheral devices, storing data during transfers.
- Data Acquisition Systems: Used in data acquisition systems to store sampled data before processing.
Features:
- 10-Bit Register: Provides 10 bits of storage.
- D-Type Flip-Flops: Uses D-type flip-flops for data storage.
- Fast CMOS Technology (FCT): High-speed operation with low power consumption.
- Three-State Outputs: Outputs can be placed in a high-impedance state for bus isolation.
- Clock Enable: A clock enable input controls when the data is latched into the register.
- SOIC Package: Available in a small outline integrated circuit (SOIC) package for space-saving PCB design.
Benefits:
- Improved System Performance: High-speed operation reduces delays in data transfer, improving overall system performance.
- Reduced Power Consumption: Low power consumption reduces heat dissipation and extends battery life.
- Increased System Flexibility: Three-state outputs allow for versatile bus management.
- Simplified System Design: Provides a convenient and efficient way to store and buffer data.
- Space-Saving Design: SOIC package allows for compact PCB layouts.
The IDT74FCT821ATSO typically operates at a supply voltage of 5V or 3.3V and requires decoupling capacitors for stable operation. Data is latched into the register on the rising edge of the clock signal when the clock enable input is active. The three-state outputs can be enabled or disabled using the output enable input, allowing the register to be connected to a bus without loading it when not actively transmitting data. 'A' in the part number typically denotes an improved version or a specific characteristic and the 'SO' signifies the SOIC package. Datasheets provide detailed timing and electrical specifications.
