BSZ15DC02KDHXTMA1 BSZ15DC02KDHXTMA1 Real Image
Same model may have multiple batches, images only for reference.
BSZ15DC02KDHXTMA1 BSZ15DC02KDHXTMA1 Real Image
BSZ15DC02KDHXTMA1 BSZ15DC02KDHXTMA1 Real Image
Same model may have multiple batches, images only for reference.

BSZ15DC02KDHXTMA1

Part No BSZ15DC02KDHXTMA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N/P-CH 20V 5.1/3.2A TDSON
Datasheet
BSZ15DC02KDHXTMA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Estimated Pruduction Lead Time 51 Weeks
Features Mosfet Array N and P-Channel Complementary 20V 5.1A, 3.2A 2.5W Surface Mount PG-TSDSON-8-FL
Manufacturer Infineon Technologies
Series Automotive, AEC-Q101, HEXFET®
Package Reel - TR
Operating Temperature Range -55°C ~ 175°C (TJ)
Mounting Surface Mount
Package 8-PowerTDFN
Case / Package PG-TSDSON-8-FL
Family Name BSZ15DC02
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Part Number SP000961028, BSZ15DC02KDHXTMA1-ND, BSZ15DC02KDHXTMA1CT, BSZ15DC02KDHXTMA1DKR, BSZ15DC02KDHXTMA1TR
Quantity per package 5000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 913641-BSZ15DC02KDHXTMA1
Ultra Librarian 3D Model Ultra Librarian BSZ15DC02KDHXTMA1 CAD Model

Description

The Infineon Technologies 913641-BSZ15DC02KDHXTMA1 is an automotive, AEC-Q101, HEXFET Mosfet Array N and P-Channel Complementary 20V 5.1A, 3.2A 2.5W Surface Mount PG-TSDSON-8-FL.

  • Manufacturer: Infineon Technologies
  • Certification: Automotive, AEC-Q101, HEXFET
  • Type: Mosfet Array N and P-Channel Complementary
  • Voltage: 20V
  • Current: 5.1A, 3.2A
  • Power: 2.5W
  • Mounting: Surface Mount
  • Package: PG-TSDSON-8-FL, 8-PowerTDFN
  • Drain-to-Source Voltage: 20V
  • Continuous Drain Current @ 25°C: 5.1A and 3.2A
  • Power Dissipation (Max): 2.5W
  • Operating Temperature Range: -55°C ~ 175°C (TJ)
  • Supply and Demand Status: Balanced
