The BTT6050-2EKA is a high-side power switch from Infineon Technologies, designed for automotive and industrial applications. This smart power high-side switch is part of the PROFET™ family and offers integrated protection features and diagnostic capabilities, enhancing system reliability and safety.

Applications

• Automotive lighting (e.g., headlights, taillights, interior lights)
• Automotive body control modules
• Industrial automation
• Power distribution in electronic systems
• Solenoid and relay driving

Features

• High-side switch: Controls the high side of the load, simplifying wiring and offering better protection.
• Overload protection: Protects the switch and the load from excessive current draw.
• Short-circuit protection: Shuts down the switch in the event of a short circuit to prevent damage.
• Overtemperature protection: Disables the switch if the temperature exceeds a safe limit.
• Reverse polarity protection: Protects the switch from damage if the polarity is reversed.
• Diagnostic feedback: Provides diagnostic information about the switch's status (e.g., overload, short circuit, overtemperature).
• Logic level input: Compatible with standard logic levels for easy interfacing with microcontrollers.

Benefits

• Enhanced system reliability: Integrated protection features ensure reliable operation and prevent damage to the switch and the load.
• Simplified design: High-side switching simplifies wiring and reduces component count.
• Improved safety: Protection against overload, short circuit, overtemperature, and reverse polarity enhances safety.
• Diagnostic capabilities: Diagnostic feedback enables proactive fault detection and troubleshooting.
• Automotive qualified: Meets the stringent requirements of automotive applications.

Additional Details

The BTT6050-2EKA operates with a typical supply voltage of 12V in automotive applications, but can function with a wide voltage range. It is available in a PG-DSO-8 package. The diagnostic feedback is typically provided through a status pin that can be monitored by a microcontroller. The switch's current limiting and thermal shutdown thresholds are precisely defined in the datasheet. The device is compliant with automotive standards such as RoHS and REACH. Detailed electrical characteristics, timing diagrams, and application notes can be found in the Infineon Technologies datasheet.
