The 603631-IPP220N25NFD is a N-Channel MOSFET transistor from Infineon Technologies.

• Series: It is part of the OptiMOS™FD series, which is known for its high performance and reliability.
• Drain to Source Voltage (Vdss): This MOSFET has a drain to source voltage (Vdss) of 250 V and a continuous drain current (Id) of 61A @ 25°C.
• Rds On (Max): The Rds On (Max) is 22mOhm @ 61A and 10V.
• Power Dissipation: With a power dissipation of 300W, this MOSFET is suitable for various applications in the electronics industry.
• Package Type: The package type is TO-220-3, which allows for through-hole mounting.
• Gate Charge (Qg): The gate charge (Qg) is 86 nC @ 10V, and the input capacitance (Ciss) is 7076 pF @ 125V.
• Operating Temperature Range: The operating temperature range is -55°C to 175°C.
• Benefit: This MOSFET is an excellent choice for applications that require high voltage and current capabilities, such as power supplies, motor control, and inverters.
